* @brief Determines best dividers to get a target clock rate
* @param[in] UARTx Pointer to selected UART peripheral, should be:
* - LPC_UART0: UART0 peripheral
* - LPC_UART1: UART1 peripheral
* - LPC_UART2: UART2 peripheral
* - LPC_UART3: UART3 peripheral
* @param[in] baudrate Desired UART baud rate.
* @return Error status, could be:
* - SUCCESS
* - ERROR
**********************************************************************/
static Status uart_set_divisors(LPC_UART_TypeDef *UARTx, uint32_t baudrate)
{
Status errorStatus = ERROR;
uint32_t uClk;
uint32_t d, m, bestd, bestm, tmp;
uint64_t best_divisor, divisor;
uint32_t current_error, best_error;
uint32_t recalcbaud;
/* get UART block clock */
if (UARTx == LPC_UART0)
{
uClk = CLKPWR_GetPCLK (CLKPWR_PCLKSEL_UART0);
}
else if (UARTx == (LPC_UART_TypeDef *)LPC_UART1)
{
uClk = CLKPWR_GetPCLK (CLKPWR_PCLKSEL_UART1);
}
else if (UARTx == LPC_UART2)
{
uClk = CLKPWR_GetPCLK (CLKPWR_PCLKSEL_UART2);
}
else if (UARTx == LPC_UART3)
{
uClk = CLKPWR_GetPCLK (CLKPWR_PCLKSEL_UART3);
}
/* In the Uart IP block, baud rate is calculated using FDR and DLL-DLM registers
* The formula is :
* BaudRate= uClk * (mulFracDiv/(mulFracDiv+dividerAddFracDiv) / (16 * (DLL)
* It involves floating point calculations. That's the reason the formulae are adjusted with
* Multiply and divide method.*/
/* The value of mulFracDiv and dividerAddFracDiv should comply to the following expressions:
* 0 < mulFracDiv <= 15, 0 <= dividerAddFracDiv <= 15 */
best_error = 0xFFFFFFFF; /* Worst case */
bestd = 0;
bestm = 0;
best_divisor = 0;
for (m = 1 ; m <= 15 ;m++)
{
for (d = 0 ; d < m ; d++)
{
divisor = ((uint64_t)uClk<<28)*m/(baudrate*(m+d));
current_error = divisor & 0xFFFFFFFF;
tmp = divisor>>32;
/* Adjust error */
if(current_error > ((uint32_t)1<<31)){
current_error = -current_error;
tmp++;
}
if(tmp<1 || tmp>65536) /* Out of range */
continue;
if( current_error < best_error){
best_error = current_error;
best_divisor = tmp;
bestd = d;
bestm = m;
if(best_error == 0) break;
}
} /* end of inner for loop */
if (best_error == 0)
break;
} /* end of outer for loop */
if(best_divisor == 0) return ERROR; /* can not find best match */
recalcbaud = (uClk>>4) * bestm/(best_divisor * (bestm + bestd));
/* reuse best_error to evaluate baud error*/
if(baudrate>recalcbaud) best_error = baudrate - recalcbaud;
else best_error = recalcbaud -baudrate;
best_error = best_error * 100 / baudrate;
if (best_error < UART_ACCEPTED_BAUDRATE_ERROR)
{
if (((LPC_UART1_TypeDef *)UARTx) == LPC_UART1)
{
((LPC_UART1_TypeDef *)UARTx)->LCR |= UART_LCR_DLAB_EN;
((LPC_UART1_TypeDef *)UARTx)->/*DLIER.*/DLM = UART_LOAD_DLM(best_divisor);
((LPC_UART1_TypeDef *)UARTx)->/*RBTHDLR.*/DLL = UART_LOAD_DLL(best_divisor);
/* Then reset DLAB bit */
((LPC_UART1_TypeDef *)UARTx)->LCR &= (~UART_LCR_DLAB_EN) & UART_LCR_BITMASK;
((LPC_UART1_TypeDef *)UARTx)->FDR = (UART_FDR_MULVAL(bestm) \
| UART_FDR_DIVADDVAL(bestd)) & UART_FDR_BITMASK;
}
else
{
UARTx->LCR |= UART_LCR_DLAB_EN;
UARTx->/*DLIER.*/DLM = UART_LOAD_DLM(best_divisor);
UARTx->/*RBTHDLR.*/DLL = UART_LOAD_DLL(best_divisor);
/* Then reset DLAB bit */
UARTx->LCR &= (~UART_LCR_DLAB_EN) & UART_LCR_BITMASK;
UARTx->FDR = (UART_FDR_MULVAL(bestm) \
| UART_FDR_DIVADDVAL(bestd)) & UART_FDR_BITMASK;
}
errorStatus = SUCCESS;
}
return errorStatus;
}
将此函数替换库中函数。
